Zhengzhou Al-Electric Import& Export Co., Ltd.
|
| Price: | 0.3~24.0 USD |
| Payment Terms: | T/T,L/C,WU |
| Place of Origin: | Henan, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
| Type | Nominal area (mm 2 ) | Structure of conductor (mm) | Insulation thickness (mm) | Number of core |
| YGZ YGZB | 0.75 | 24/0.2 | 0.6 | 37 or below |
| 1.0 | 32/0.2 | 0.6 | ||
| 1.5 | 30/0.2 | 0.7 | ||
| 2.5 | 49/0.2 | 0.8 |
| Type | Nominal area (mm 2 ) | Structure of conductor (mm) | Insulation thickness (mm) | Number of core |
| YGC YGCB | 4 | 56/0.3 | 1 | 2-19 |
| 6 | 84/0.3 | 1 | 2-10 | |
| 10 | 84/0.3 | 1.1 | ||
| 16 | 126/0.4 | 1.1 | 2-5 | |
| 25 | 196/0.4 | 1.5 | ||
| 35 | 276/0.4 | 1.4 | ||
| 50 | 396/0.4 | 1.5 | ||
| 70 | 360/0.5 | 1.6 | ||
| 95 | 475/0.5 | 1.8 |
Cores ×Nominal section (mm2) | conductive core (mm) | Average outer diameter(mm2) | 20°C conductor resistance | Reference weight (kg/km) | |||
number diameter of core | Minimum | Maximum l | Copper core | tin-welled Copper core | YZ | YZW | |
3×1.5+1×1 | 30/0.25+32/0.2 | 9.4 | 12 | 13.2 | 13.6 | 170.1 | 181.9 |
3×2.5+1×1.5 | 49/0.25+30/0.25 | 11 | 14 | 7.98 | 8.21 | 246.8 | 262.9 |
3×4+1×2.5 | 56/0.3+49/0.25 | 13 | 16 | 4.95 | 5.09 | 359.1 | 380.5 |
3×6+1×4 | 84/0.3+56/0.3 | 14.5 | 19.5 | 3.3 | 3.39 | 542.1 | 572.5 |
