IEC standard high voltage power cable power cable manufacturer from China Zhengzhou Al-Electric Import& Export Co., Ltd.

Price:	0.3~24.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: power cable

Production Capacity: 50000m/week

Delivery Date: 15days for one container

Type: High Voltage

Jacket: Rubber

Brand Name: Aodian

voltage: high voltage

Conductor: copper

size: 16mm2 25mm2 35mm2

Means of Transport: Ocean,Land,Air

Packing: standard wooden drum or ste...

Application: Industrial

Insulation Material: Rubber

Conductor Material: Copper

type: power cable

insulation: rubber

color: red/black/blue/yellow/green...

standard: IEC

1. heat resistant
2. decades of manufacture
3. pure copper wire stranded conductor
4. standards: IEC60245
5. made in China
6. fast delivery

High voltage power cable 6KV, 10KV, 15KV, 20KV, 35KV

CPE chloroprene rubber cable

1,Products introduction

Aodian450/750v rubber flexible cables copper conductor UL is used for power transporting of the power, electrical apparatus and various mobile field electrical equipment with AC rated voltage of 450/750V or below. The performance not only conforms to the Standard GB1169, GB1170, JB1601 and JB1701, but also has shaped series. as oil resistant. cold resistant and fire resistant.

2,Production range

Type Core quantity Nominal cross-sectional area of conductor(mm²) Rated voltage(V)

YZ YZW 1
2
3-5 0.75-6

0.75-6
300/500

YC YCW 1
2
3-5 1.5-400
1.5-185
1.5-185
450/750
UZ 3+1 3+2 2.5 300/500
U 3+1 3+2 2.5-70 1000(660)
JBQ 1 0.75-120 500/1140
BXR 1 0.75-400 300/500
BX BLX BXY
BXF BLXF BLXY
1
0.75-400
300/500
YH 1 10-150 200
YTYTF 6-30 0.75-6 300/500
YR YRT 1-20 1-1.5 300/500

3,Type, description and applicable scope

Type Description Installation environment

YZ YZW

Medium rubber-bushed soft cable It is used for various mobile electrical apparatus equipment, can bear general mechanical exogeni action."W" is provided with weather and oil resistan performance.

YC YCW
Heavy robber-bushed soft cable It is used for various mobile electrical apparatus equipment, and can bear greater mechanical exogeni action,"W" is provided with weather and oil resistan performance.
UZ Electrical drill cable It is used for drilling of 500V and below

U Mine mobile rubber-bushed soft cable It is used for various electrical apparatus
equipments of 1000V and below.

JBQ Copper core rubber-bushed insulated
butyronitrile sheath lead wire
It is used for leading wire of Class B insulated
electric machine of 1000V and below.
BX BLX Rubber-bushed insulated fiber braided wife Fixed laying

BXR Copper core rubber insulated fiber braided soft wire It should be installed in the door and softer place.

BXY BLXY Rubber insulated neoprene or other syntheticrubber mixture sheath wire It is should for cold crossing the pipe and fised laying.

BXF BLXF Rubber insulated neoprene or other syntheticrubber mixture sheath wire lt is suitable for cold crossing the pipe and fised laying.
YH Natural rubber sheath welder cable It is used for the welder to connect with the welding pliers
YTY TF Rubber sheath elevator cable lt is suitable for the elevator

YR YRF
Natural butylbenzene insulated and sbeath/neoprene sheath multiple-core mobile soft cable It is suitable for the electric block,driving and
exploring equipment

Photo of the 450/750v rubber flexible cables copper conductor UL

450/750v rubber flexible cables copper conductor UL
